Freshwater Protein Skimmer for Fish Farmers and Aquariums: A Game-Changer in Water Quality Management
A Freshwater Protein Skimmer is a specialized device developed for use in freshwater aquariums and fish farming systems. It is designed to remove organic waste, excess proteins, and other harmful compounds from the water, ensuring a clean and healthy environment for your fish and aquatic life. Traditionally used in saltwater systems, protein skimmers have now been optimized for freshwater tanks and are quickly becoming an essential tool for aquarium enthusiasts and fish farmers alike.
For freshwater fish farms and aquariums, balancing water quality can be challenging. Organic waste, such as fish waste, uneaten food, and decaying plants, can accumulate and harm the delicate balance of the water. Freshwater protein skimmers work to remove these harmful substances efficiently, creating a healthier, more stable aquatic environment.
The Freshwater protein skimmer / foam fractionator produces fine and thick constant air bubbles in order to generate sufficient skimming. The skimmer is installed in pre-smolt stage freshwater tanks. This is the stage that farms need better water parameters to achieve optimal salmon growth. The concern is that these pre-smolt tanks run on fresh water and traditional protein skimmers could not achieve significant foam fractionation.
Our design and engineering department spent over 12 months testing different venturi injectors on skimmer bodies while feeding tank water with special venturi pumps to obtain the needed pressure and achieve high levels of air infusion into the water cyclone within the skimmer body. After many trials and FEA studies, our fresh water protein skimming is now achieving equal if not better to salt water viscous results.
It is very important that our fresh water protein skimmers contribute significantly to farms biosecurity by obtaining far better water parameters to existing tanks. Our equipment is designed from scratch and delivers the best quality of protein removal from any other equivalent foam fractionator in the market. Better water quality results to more fish and feed in the same tank.
The new freshwater protein skimmer has an upgraded body, high efficiency protein cap collector, higher head pump, new specially designed Venturi and optionally, we offer foam level automated controllers. The new automation is a must-have addition for those farms that seek to operate under controlled fresh water conditions.
View below technical data, specifications and competitive pricing for your salmonid hatchery or any other demanding fresh water aquaculture application.
wdt_ID | PROTEIN SKIMMER-F | PSF-05 | PSF-08 | PSF-10 | PSF-15 | PSF-25 | PSF-30 | PSF-50 | PSF-70 | PSF-90 | PSF-100 | PSF-130 | PSF-150 | PSF-180 | PSF-200 | PSF-250 |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
1 | FootprintDepth [mm] | 600 | 600 | 600 | 1810 | 2100 | 2820 | 2900 | 3805 | 4185 | ||||||
2 | FootprintWidth [mm] | 1043 | 1525 | 2220 | 2550 | 2810 | 3350 | 4000 | 4775 | 5435 | ||||||
3 | Diameter[mm] | 400 | 400 | 500 | 500 | 600 | 700 | 800 | 1200 | 1100 | 1200 | 1300 | 1500 | 1800 | 2000 | 2500 |
4 | Height[mm] | 1500 | 1800 | 2100 | 2100 | 2400 | 2500 | 2800 | 28000 | 3000 | 3000 | 3200 | 3300 | 3300 | 3300 | 3300 |
5 | Installed Power [Watts] | 370 | 370 | 370 | 550 | 750 | 1100 | 1100 | 1100 | 1100 | 2200 | 2200 | 2200 | 2200 | 3300 | 3300 |
6 | Basic Unit Total Electric Consumption [kWh] | 75 | 1 | 3 | 3 | 4 | 84 | 88 | 11 | 195 | ||||||
7 | Supply Voltage (50Hz) [V] | 220 | 220 | 220 | 220 | 220 | 220 | 220 | 220 | 220 | 220 | 220 | 220 | 220 | 220 | 220 |
8 | Inlet Size[mm] | 50 | 50 | 50 | 63 | 63 | 75 | 90 | 110 | 110 | 160 | 160 | 160 | 160 | 200 | 200 |
9 | Inlet Qty[pcs] | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
10 | Inlet Level [mm] | 1000 | 1200 | 1500 | 1500 | 1900 | 1900 | 2000 | 2000 | 1800 | 1800 | 1900 | 2000 | 2000 | 2000 | 2000 |
11 | Outlet Size[mm] | 63 | 75 | 90 | 90 | 110 | 110 | 160 | 160 | 160 | 200 | 200 | 200 | 200 | 250 | 250 |
12 | Outlet Qty[pcs] | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
13 | Outlet Level[mm] | 1000 | 1200 | 1500 | 1600 | 1900 | 2000 | 2100 | 2100 | 2000 | 2000 | 2000 | 2100 | 2100 | 2100 | 2100 |
14 | Body Volume[m³] | 24 | 71 | 129 | 274 | 45 | 809 | 145 | 23 | 29 | ||||||
15 | Minimum-Maximum operation water level[mm] | 1353 | 1705 | 1949 | 2230 | 2806 | 2922 | 3095 | 3665 | 3665 | ||||||
16 | Foam Collector effluent connection size[mm] | 50 | 50 | 63 | 63 | 63 | 90 | 90 | 90 | 90 | ||||||
17 | Max Flow Rate[m³/hr] | 5 | 8 | 10 | 15 | 25 | 30 | 50 | 70 | 90 | 100 | 130 | 150 | 180 | 200 | 250 |
18 | Max Flow Dwell Time[second] | 38 | 41 | 21 | 35 | 45 | 49 | 42 | 64 | 70 | ||||||
19 | @1min Dwell Time Flow Rate[m³] | 14 | 43 | 77 | 1644 | 270 | 485 | 870 | 1380 | 1740 | ||||||
20 | @1.5 min Dwell Time Flow Rate[m³/hr] | 96 | 284 | 516 | 1096 | 180 | 3236 | 580 | 920 | 1160 | ||||||
21 | @2 min Dwell Time Flow Rate[m³/hr] | 7 | 21 | 39 | 82 | 135 | 243 | 435 | 690 | 870 | ||||||
22 | Dry Weight[kg] | 100 | 180 | 262 | 420 | 530 | 760 | 1185 | 1960 | 2070 | ||||||
23 | Operational Weight[kgs] | 435 | 970 | 1650 | 3265 | 5365 | 9800 | 13585 | 25000 | 29000 | ||||||
24 | Body Material | PP | PP | PP | PP | PP | PP | PP | PP | PP | PP | PP | PP | PP | PP | PP |
25 | Venturi Pump Qty [pcs] | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | ||||||
26 | Venturi Pump Model | 21 | 21 | 21 | 21 | 21 | 0 | 0 | 0 | 0 | ||||||
27 | Nominal Air Suction [Nm³/hr] | 67 | 10 | 30 | 30 | 40 | 72 | 90 | 130 | 180 | ||||||
PROTEIN SKIMMER-F | PSF-05 | PSF-08 | PSF-10 | PSF-15 | PSF-25 | PSF-30 | PSF-50 | PSF-70 | PSF-90 | PSF-100 | PSF-130 | PSF-150 | PSF-180 | PSF-200 | PSF-250 |
wdt_ID | PROTEIN SKIMMER OPTIONAL FEATURES | PSM-14 | PSM/F-22 | PSM/F-62 | PSM/F-220 | PSM/F-280 | PSM/F-360 | PSM/F-600 | PSM/F-800 | PSM/F-1300 | PSM/F-1500 |
---|---|---|---|---|---|---|---|---|---|---|---|
1 | Electrical Control Panel | optional | optional | optional | optional | optional | optional | optional | optional | optional | optional |
2 | Electrical Control Panel Footprint | 185x550x770 | 185x550x770 | 185x550x770 | included in unit | included in unit | included in unit | included in unit | included in unit | included in unit | included in unit |
3 | Foam Collector Autowash | Solenoid | Solenoid | Solenoid | Solenoid | Motorized | Motorized | Motorized | Motorized | Motorized | Motorized |
4 | Overflow Switch | N/A | optional | optional | optional | optional | optional | optional | optional | optional | optional |
5 | ORP Control | optional | optional | optional | optional | optional | optional | optional | optional | optional | optional |
6 | Foam Level Automation | N/A | N/A | N/A | optional | optional | optional | optional | optional | optional | optional |
7 | Operational Platform | N/A | N/A | N/A | N/A | N/A | optional | optional | optional | optional | optional |
8 | Passive Ozone destruct | optional | optional | optional | optional | N/A | N/A | N/A | N/A | N/A | N/A |
9 | Quick Retractable ORP/PH Probe Fitting | optional | optional | optional | optional | optional | optional | optional | optional | optional | optional |
10 | PS Venturi Pump | optional | optional | optional | optional | optional | optional | optional | optional | optional | optional |
11 | Ozone Gas Rotameter | optional | optional | optional | optional | optional | optional | optional | optional | optional | optional |
12 | Outer Wash Port & Valve for Chemical Dosing | optional | optional | optional | optional | optional | optional | optional | optional | optional | optional |
13 | Reuse of off gassed ozone | optional | optional | optional | optional | optional | optional | optional | optional | optional | optional |
14 | Sight Glass | optional | optional | optional | optional | optional | N/A | N/A | N/A | N/A | N/A |
15 | Manhole (PP Cover) | N/A | N/A | N/A | N/A | N/A | optional | optional | optional | optional | optional |
16 | Manhole (Acrylic Cover) | N/A | N/A | N/A | N/A | N/A | optional | optional | optional | optional | optional |
17 | Ozone Inlet Solenoid Valve SS 316 Body | optional | optional | optional | optional | optional | optional | optional | optional | optional | optional |
18 | PS Camera | optional | optional | optional | optional | optional | optional | optional | optional | optional | optional |
19 | PS PLC Controller | optional | optional | optional | optional | optional | optional | optional | optional | optional | optional |
PROTEIN SKIMMER OPTIONAL FEATURES | PSM-14 | PSM/F-22 | PSM/F-62 | PSM/F-220 | PSM/F-280 | PSM/F-360 | PSM/F-600 | PSM/F-800 | PSM/F-1300 | PSM/F-1500 |
* MAT-KULING AS™ preserves the right to update anytime the listed prices (if any). Every effort has been made so that the above specs are accurate. However please contact our Sales Department for up to date technical data, electrical specs according to your regional requirements and current Ex-Works pricelist. The listed prices are for the basic equipment and do not include any optional components.
